Width:
8.39in
Height:
3.46in
Length:
8.27in
Weight:
2.5kg
Product Type:
Function Generator
FM Modulation:
Yes
Interface Type:
USB
Variable Sweep:
Yes
Output Amplitude:
10 mVpp to 10 Vpp (into 50 Ω), 20 mVpp to 20 Vpp (open circuit)
Output Impedance:
50Ω
TTL Output Level:
5V Pk-Pk
Digital Frequency:
Yes
Time Base Accuracy:
0.01 % ± 0.006 Hz
Standards/Approvals:
EMC 2004/108/EC, EN55011, EN61010, EN55082 Safety Low Voltage 2006/95/EC
Digital Amplitude and Offset:
Yes
Internal Linear and Log Sweep:
Yes
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
0°C
Maximum Frequency Range Sinewave:
20MHz
Minimum Frequency Range Sinewave:
0.01Hz
Maximum Frequency Range Triangle/Saw:
2MHz
Minimum Frequency Range Triangle/Saw:
0.01Hz
Internal and External Amplitude Modulation:
Yes
Maximum Frequency Range Square Pulse/Arbitrary Waveform:
20MHz
Minimum Frequency Range Square Pulse/Arbitrary Waveform:
0.01Hz
