Width:
210mm
Height:
88mm
Length:
213mm
Weight:
2.5kg
Calibrated:
RSCAL
Product Type:
Function Generator
FM Modulation:
Yes
Interface Type:
USB
Variable Sweep:
Yes
Input Impedance:
10kΩ
Output Amplitude:
20 V Pk-Pk
TTL Output Level:
5V Pk-Pk
Digital Frequency:
Yes
Time Base Accuracy:
0.01 % ± 0.006 Hz
Standards/Approvals:
Low Voltage 2006/95/EC, EN61010, EN55011, EMC 2004/108/EC, EN55082
Digital Amplitude and Offset:
Yes
Internal Linear and Log Sweep:
Yes
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
0°C
Maximum Frequency Range Sinewave:
12MHz
Minimum Frequency Range Sinewave:
0.01Hz
Maximum Frequency Range Triangle/Saw:
1MHz
Minimum Frequency Range Triangle/Saw:
0.01Hz
Internal and External Amplitude Modulation:
Yes
Maximum Frequency Range Square Pulse/Arbitrary Waveform:
20MHz
Minimum Frequency Range Square Pulse/Arbitrary Waveform:
0.01Hz
