Current Rating:
47.3 A
Supply Voltage:
500 V
For Use With:
Asynchronous Motors, Synchronous Motors
Function:
Motor Control
Better World Claim:
Saves energy
Standards Met:
CE, CSA, cUL, EAC, EN 954-1, EN ISO 13849-1, EN ISO 13849-2, IEC 60204-1, IEC 6100, IEC 61158, IEC 61508, IEC 61784, IEC/EN 60721, NOM 117, RCM, UL
Drive Type:
Variable Frequency
Overall Length:
404mm
Phase:
3
Overall Depth:
232mm
IP Rating:
IP20
STO:
Yes
Hazardous Area Certification:
ATEX
Output Frequency:
0.1 → 599Hz
Special Features:
Enhanced Automation Capabilities, Even at Low Speed & Dynamic Accuracy for Start/Stop Application, Open-Loop Motor Control Combined, Variable Speed Drive Improves Machine Effectiveness
Better World Verification:
Green Premium
Better World Product:
Yes
Mounting Type:
DIN Rail
Series:
ATV320
Overall Width:
180mm
Filter Included:
Yes
Control Panel:
Yes
Power Rating:
15 kW
Field Bus Communication Type:
Profibus
HTSUS:
8537.10.9170
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-10°C ~ 60°C
Current - Output:
33A
Interface:
-
Wattage - Load:
15000 W
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Number of Motors:
1
standardLeadTime:
9 Weeks
Features:
-
Mounting Type:
Chassis Mount
Series:
Altivar
Voltage - Load:
380 ~ 500V
Packaging:
Box
Voltage - Supply:
-
ECCN:
EAR99
