RECOM LED Driver, 90 to 264V AC Input Voltage, 100mA Input Current - RACD04 Series - RACD04-700
Keep your domestic or commercial lighting system regulated and operating reliably with this LED driver from RECOM. It helps to ensure a constant supply of power to your LEDs, even if their electrical properties change as they heat up. You can discretely mount this unit under shelves or in constricted areas, thanks to its low profile of 21mm. As this driver has a maximum power output of 4.2W, it's a good choice for high-powered lighting systems.
Features & Benefits
• IP65-rated enclosure that's dust-tight and protected against low-pressure water sprays from any direction
• Plastic housing to help prevent shocks during installation and use
• Immune to voltage dips and brief power supply interruptions to keep LEDs functioning reliably
• Flame-retardant enclosure won't catch alight in the event of a fire Applications • Shopping centres
• Office blocks
• Retail outlets and hotels Is this driver protected against high temperatures? Yes, for your safety this driver includes over-temperature protection. When a fault is diagnosed and fixed, the unit auto-recovers, so there's no need for you to manually reset it.
• Plastic housing to help prevent shocks during installation and use
• Immune to voltage dips and brief power supply interruptions to keep LEDs functioning reliably
• Flame-retardant enclosure won't catch alight in the event of a fire Applications • Shopping centres
• Office blocks
• Retail outlets and hotels Is this driver protected against high temperatures? Yes, for your safety this driver includes over-temperature protection. When a fault is diagnosed and fixed, the unit auto-recovers, so there's no need for you to manually reset it.

LED Driver, 3 → 6V dc Output, 4.2W Output, 700mA Output, Constant Current
Manufacturer:
Recom
Manufacturer Part No:
RACD04-700
Enrgtech Part No:
ET16796216
Warranty:
Manufacturer
£ 10.42
Checking for live stock
Output Voltage:
3 → 6V dc
Maximum Output Power:
4.2W
Output Current:
700mA
Dimmable:
No
Input Voltage:
90 → 264 V ac
Operation:
Constant Current
LED Driver Type:
LED Driver
AC or DC Input Voltage:
ac
IP Rating:
IP65
Current Rating:
0 → 700mA
Number of Outputs:
1
Voltage Rating:
264V ac
