LED Driver, 2 → 24V dc Output, 12W Output, 500mA Output, Constant Current

Output Voltage:

2 → 24V dc

Maximum Output Power:

12W

Output Current:

500mA

Dimmable:

No

Input Voltage:

198 → 264 V ac

Operation:

Constant Current

LED Driver Type:

LED Driver

AC or DC Input Voltage:

ac

IP Rating:

IP20

Current Rating:

0 → 500mA

Series:

RACD12-LP

Voltage Rating:

264V ac

Number of Outputs:

1

Configuration:

Enclosed

Standards Met:

CB, CE, EN 55015, EN 61000-3-2 Class C, EN 61000-3-3, EN 61000-4-11 Criteria B, EN 61000-4-11 Criteria C, EN 61000-4-2 Criteria B, EN 61000-4-3 Criteria A, EN 61000-4-4 Criteria B, EN 61000-4-5 Criteria C, EN 61000-4-6 Criteria A, EN 61347-1, EN 61347-2-13, EN 61493, EN 61547, ENEC, ERP Compliant, IEC 61347-1, IEC 61347-2-13, IEC/EN 62384

Primary Type:

AC-DC
