Kingbright SMT Chip LED 1615 (0605) Package
Kingbright's 1615 family of surface mount (SMT) LEDs have the standard 0605 footprint. These bi-colour LEDs are available in a range of colour combinations. They are also available in various lens type options. The 1615 LEDs are suitable for applications such as backlighting and indicators.
Features of the 1615 series:
Bi-colour LEDs
Standard 0605 package
Dimensions: 3.2 x 2.4 mm
Low power consumption
Features of the 1615 series:
Bi-colour LEDs
Standard 0605 package
Dimensions: 3.2 x 2.4 mm
Low power consumption
2.5 V Green & Red LED 1616 (0606) SMD, KPTB-1615ESGC
Manufacturer:
Kingbright
Manufacturer Part No:
KPTB-1615ESGC
Enrgtech Part No:
ET13892987
Warranty:
Manufacturer
£ 0.20
Checking for live stock
LED Colours:
Green, Red
Package Type:
1616 (0606)
Mounting Type:
Surface Mount
Number of LEDs:
2
Forward Voltage:
2.5 V
Luminous Intensity:
12 mcd, 15 mcd
Number of Pins:
4
Viewing Angle:
120 °
Lens Shape:
Rectangle
Dominant Wavelength:
568 / 617 nm
Lens Colour:
Clear
Dimensions:
1.6 x 1.5 x 0.7mm
