SN74LVC1G27DBVR 3-Input NOR Logic Gate, 6-Pin SOT-23

Logic Function:

NOR

Mounting Type:

Surface Mount

Number of Elements:

1

Number of Inputs per Gate:

3

Schmitt Trigger Input:

No

Package Type:

SOT-23

Pin Count:

6

Logic Family:

LVC

Input Type:

Differential

Maximum Operating Supply Voltage:

5.5 V

Maximum High Level Output Current:

-4mA

Maximum Propagation Delay Time @ Maximum CL:

20.5 ns @ 50 pF

Minimum Operating Supply Voltage:

1.65 V

Maximum Low Level Output Current:

32mA

Width:

1.75mm

Height:

1.3mm

Length:

3.05mm

Output Type:

Single Ended

Maximum Operating Temperature:

+125 °C

Propagation Delay Test Condition:

50pF

Minimum Operating Temperature:

-40 °C

Dimensions:

3.05 x 1.75 x 1.3mm
