The SICK's V3 pre-wired magnetic microswitch,PNP o/p. Its net unit weight is 50.4 Grams. It is rectangular in shape. Its housing material is plastic, polyamid. Its Switching frequency is 5,000 Hz.
Supply voltage is 10 V DC - 30 V DC
Dimension is 10.3 mm x 28 mm x 16 mm
Safe sensing range Sa is 48.6 mm
Dimension is 10.3 mm x 28 mm x 16 mm
Safe sensing range Sa is 48.6 mm
Rectangular Magnetic Proximity Sensor, NO, , 300mA, IP67
Manufacturer:
SICK
Manufacturer Part No:
MQ10-60APSKU0
Enrgtech Part No:
ET19999077
Warranty:
Manufacturer
£ 71.90
Checking for live stock
Switch Shape:
Rectangular
Normal State Configuration:
NO
Output Type:
PNP
Maximum Current:
300mA
Maximum DC Voltage:
30V
Switching Frequency:
5kHz
Total Length:
37mm
Length:
28mm
Minimum Operating Temperature:
-25°C
Maximum Operating Temperature:
+75°C
Depth:
16mm
Width:
10.3mm
