STM32F429I Evaluation Board The STMicroelectronics STM32429I-EVAL ARM^® Cortex™ M4 evaluation board works with the STM32F429 MCUs. This development platform allows the user to develop quick applications and has an integrated ST-LINK/V2 that will provide an embedded debugger and programmer for the STM32 microcontroller. Microcontroller: STM32F429NIH6
Colour TFT LCD (4.3" touchscreen)
Power supply (5 V): Power jack; ST-LINK/V2 USB connector; USB HS connector; USB FS1 connector; USB FS2 connector; daughterboard
RS-232 communication
SDIO interface: Micro SD card
Embedded ST-LINK/V2 (JTAG/SWD and ETM trace)
SDRAM (8M x 32-bit); SRAM (1M x 16-bit) and NOR Flash (8M x 16-bit)
Push buttons: Reset wakeup and tamper
Status LEDs x 4
RTC; Potentiometer; Joystick; Camera module; IrDA transceiver; Motor control connector; SAI Audio DAC; Stereo digital microphone; RF EEPROM
