Width:
55mm
Height:
212mm
Length:
100mm
Series:
IDM 103N/105N/106N
Weight:
620g
True RMS:
Yes
Battery Life:
300h
Battery Type:
JIS 006P, IEC 6F22, NEDA 1604
Display Type:
Digital
Model Number:
IDM106N
Product Type:
Multimeter
Multimeter Type:
Handheld
Maximum Frequency:
400MHz
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Peak, Resistance, Temperature
AC Current Accuracy:
±1.5 % rdg + 5 Digits
AC Voltage Accuracy:
±1.5 % rdg + 5 Digits
DC Current Accuracy:
±0.4 % rdg + 2 Digits
DC Voltage Accuracy:
±0.1 % rdg + 2 Digits
Standards/Approvals:
No
AC Current Resolution:
10μA ac
AC Voltage Resolution:
0.1mV ac
DC Current Resolution:
10μA ac
DC Voltage Resolution:
100 μV dc
Resistance Resolution:
100mΩ
Safety Category Level:
CAT II, CAT III
Safety Category Voltage:
1000V
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
0°C
Maximum AC Current Measurement:
10A ac
Maximum AC Voltage Measurement:
1kV ac
Maximum DC Current Measurement:
10A dc
Maximum DC Voltage Measurement:
1kV dc
Maximum Resistance Measurement:
40mΩ
Resistance Measurement Accuracy:
±0.4 % rdg + 2 Digits
