Width:
302mm
Height:
107mm
Length:
265mm
Series:
IDM-8341/8342
Weight:
2.9kg
True RMS:
Yes
Calibrated:
RSCAL
Display Type:
Digital
Model Number:
IDM8341
Power Source:
Mains
Product Type:
Multimeter
Multimeter Type:
Bench
Maximum Frequency:
1MHz
Functions Measured:
AC Current, AC Voltage, Capacitance, Conductance, DC Current, DC Voltage, Diode Test, Frequency, Resistance, RMS, Temperature
AC Current Accuracy:
±0.5 % rdg + 20 Digits
AC Voltage Accuracy:
±0.35 % rdg
DC Current Accuracy:
0.02 % rdg
DC Voltage Accuracy:
0.02 % rdg
Standards/Approvals:
No
AC Current Resolution:
0.01μA ac
AC Voltage Resolution:
10μV ac
DC Current Resolution:
10nA dc
DC Voltage Resolution:
10 μV dc
Resistance Resolution:
10mΩ
Safety Category Level:
CAT II, CAT III, CAT IV
Safety Category Voltage:
600V
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
0°C
Maximum AC Current Measurement:
10A ac
Maximum AC Voltage Measurement:
750V ac
Maximum DC Current Measurement:
10A dc
Maximum DC Voltage Measurement:
1kV dc
Maximum Resistance Measurement:
50mΩ
Resistance Measurement Accuracy:
±0.1 % rdg + 3 Digits
