RS PRO RSDM3045X Digital Multimeter with 4 digits readings resolution Introducing the RSDM3045X digital multimeter from RS PRO, a highly reliable digital multimeter designed with 4 (66000 count) digits readings resolution and dual-display, ideal for high-precision, multifunction and automatic measurement. This multimeter features a clear and precise 4.3" TFT-LCD display and user-friendly interface, providing an excellent user experience. The interface includes as standard: USB device, USB host, LAN. This durable electrical tester includes true-RMS AC Voltage and AC Current measurement features, with a 1GB Nand flash size for mass storage configuration files and data files. Also included is a built-in cold terminal compensation for thermocouple, offering a versatile meter for use in a wide range of applications. Features and benefits Real 4 digits readings resolution (66000 count) Up to 150 rdgs/s measurement speed True-RMS AC Voltage and AC Current measuring 1Gb Nand flash size, Mass storage configuration files and data files Built-in cold terminal compensation for thermocouple Easy, convenient and flexible any sensor measurement control software: Ultra Sensor Standard interface: USB Device, USB Host, LAN Support remote control via commands and compatible with commands of main stream multimeters Built-in help system for enhanced user experience and troubleshooting File management (support for U-disc and local storage) Application Digital Multimeters are a type of measurement device used to test and measure a range of electrical properties such as voltage (volts), current (amps) and resistance (ohms). Using a digital output readout, the digital multimeter is connected to a device and measures typically the voltage and any resistances, giving you an output you can measure. Digital multimeters offer a wide range of AC and DC measurement capabilities to suit a variety of...

RS PRO , Bench Digital Multimeter, 10A ac 750V ac 10A dc 1000V dc 100MΩ

Manufacturer:
Manufacturer Part No:
188-2476
Enrgtech Part No:
ET19435966
Warranty:
Manufacturer
£ 350.59
Checking for live stock
Dimensions:
282 x 260 x 105mm
Capacitance Measurement Resolution:
0.001nF
DC Current Measurement Resolution:
0.01µA dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Width:
260mm
AC Current Measurement Resolution:
0.001mA ac
Best Temperature Measurement Accuracy:
±0.16 (RTD) %, ±0.5 (Type E) %, ±0.5 (Type J) %, ±0.5 (Type K) %, ±0.5 (Type N) %, ±0.5 (Type R) %, ±0.5 (Type T) %, ±0.6 (Type S) %, ±0.76 (Type B) %
Model Number p:
RSDM3045X
Resistance Measurement Resolution:
10mΩ
Best AC Voltage Accuracy:
±3% + 40 Digits
Absolute Maximum AC Current Measurement:
10A ac
Maximum Frequency:
500kHz
Absolute Maximum Capacitance Measurement:
10mF
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum Resistance Measurement:
100MΩ
Maximum Operating Temperature:
+50°C
Best Capacitance Measurement Accuracy:
±2% + 50 Digits
Minimum Operating Temperature:
0°C
AC Voltage Measurement Resolution:
0.01mV ac
Length:
282mm
Absolute Maximum Temperature Measurement:
+1000 (Type E) °C, +1200 (Type J) °C, +1300 (Type N) °C, +1370 (Type K) °C, +1760 (Type R & S) °C, +1820 (Type B) °C, +400 (Type T) °C, +660 (RTD) °C
Absolute Maximum DC Current Measurement:
10A dc
Display Type:
Digital
Best DC Current Accuracy:
±0.25% + 4 Digits
Weight:
3.8kg
Safety Category Level:
CAT I, CAT II
Best AC Current Accuracy:
±2.5% + 25 Digits
Safety Category Voltage:
CAT I 1000V CAT II 600V
Multimeter Type:
Bench
Height:
105mm
Best Resistance Measurement Accuracy:
±1.75% + 3 Digits
Best DC Voltage Accuracy:
±0.02% + 6 Digits
DC Voltage Measurement Resolution:
0.01mV dc
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
