The PCB Connector is a high-quality double row connector suitable for various applications. With a rated current of 3A and a dielectric strength of 1000V RMS, this connector offers reliable performance in demanding environments.
Insulator made of black glass filled polyester PCT-GF30-FR for durability
Contact made of Brass CuZn36Pb3 (C36000) for optimal conductivity
Mechanical life of minimum 500 cycles for long-lasting use
Operates in a temperature range of -55 to +125 °C for versatility
Underwriters Laboratories Inc. listed connector for quality assurance
Contact made of Brass CuZn36Pb3 (C36000) for optimal conductivity
Mechanical life of minimum 500 cycles for long-lasting use
Operates in a temperature range of -55 to +125 °C for versatility
Underwriters Laboratories Inc. listed connector for quality assurance
802 Series Right Angle Through Hole PCB Header, 72 Contact(s), 2.54mm Pitch, 2 Row(s)
Manufacturer:
Preci-Dip
Manufacturer Part No:
802-10-072-10-001101
Enrgtech Part No:
ET11293601
Warranty:
Manufacturer
£ 11.91
Checking for live stock
Series:
802
Pitch:
2.54mm
Number of Contacts:
72
Number of Rows:
2
Body Orientation:
Right Angle
Mounting Type:
Through Hole
