The PCB connector is a high-quality single row connector suitable for various applications. It features a pin connector with a connecting pin diameter of 0.76 mm and is designed for a mechanical life of at least 500 cycles. With a rated current of 3 A and a dielectric strength of 1000 V RMS, this connector is reliable and durable.
Insulator made of black glass filled polyester PCT-GF30-FR for added durability
Flammability rating of UL 94V-O ensures safety
Contact made of Brass CuZn36Pb3 (C36000) for excellent conductivity
Operates in temperature range of -55 to +125 °C for versatility
Underwriters Laboratories Inc. recognized for connectors use in data, signal, control, and power applications
Environmental tests include resistance to moisture, salt spray, and shock for reliability
Flammability rating of UL 94V-O ensures safety
Contact made of Brass CuZn36Pb3 (C36000) for excellent conductivity
Operates in temperature range of -55 to +125 °C for versatility
Underwriters Laboratories Inc. recognized for connectors use in data, signal, control, and power applications
Environmental tests include resistance to moisture, salt spray, and shock for reliability
800 Series Straight Through Hole PCB Header, 36 Contact(s), 2.54mm Pitch, 1 Row(s)
Manufacturer:
Preci-Dip
Manufacturer Part No:
800-10-036-10-001101
Enrgtech Part No:
ET13433152
Warranty:
Manufacturer
£ 7.50
Checking for live stock
Series:
800
Pitch:
2.54mm
Number of Contacts:
36
Number of Rows:
1
Body Orientation:
Straight
Mounting Type:
Through Hole
