Depth:
75mm
Width:
110mm
Length:
100mm
Series:
SIMATIC S7-1200
Input Type:
Analogue
Mount Type:
DIN Rail, Wall Mount
Output Type:
Relay
Product Type:
PLC CPU
Battery Backup:
Yes
Output Current:
2A
Supply Voltage:
20.4, 28.8V dc
Display Included:
No
Number of Inputs:
14
Program Capacity:
75kB
Number of Outputs:
10
Better World Claim:
Saves Energy
Standards/Approvals:
RCM, IEC, FM, cULus, CE, UL
Better World Product:
Yes
Communication Port Type:
Ethernet, Profinet
Programming Language Used:
SCL, Ladder Diagram, FBD
Maximum Operating Temperature:
60°C
Minimum Operating Temperature:
-20°C
Number of Communication Ports:
1
Depth:
75mm
Width:
110mm
Length:
100mm
Memory:
4 MB
Interface:
PROFINET
Dimensions:
100 x 110 x 75 mm
Input Type:
Analogue, Digital
Output Type:
Digital, Relay
For Use With:
SIMATIC S7-1200 Series
Kit Included:
No
Network Type:
Ethernet
Mounting Type:
DIN Rail, Wall Mount
Battery Backup:
Yes
Output Current:
2 A
Supply Voltage:
20.4 → 28.8 V dc
Display Included:
No
Number of Inputs:
14 (Digital, 2 switch as Analogue)
Program Capacity:
75 kB
Voltage Category:
24 V dc
Number of Outputs:
10 (Digital Output, Relay Output)
Better World Claim:
Saves energy
Manufacturer Series:
SIMATIC S7-1200
Better World Product:
Yes
Programming Interface:
Profinet
Communication Port Type:
Ethernet, Profinet, UDP
Number of Digital Inputs:
14
Number of Analogue Inputs:
2
Number of Digital Outputs:
10
Programming Language Used:
FBD, LAD, SCL
Maximum Operating Temperature:
+60°C
Minimum Operating Temperature:
-20°C
Number of Communication Ports:
1
