Depth:
90mm
Width:
125mm
Length:
100mm
Series:
Modicon TM
Input Type:
Digital
Mount Type:
Panel, Plate, Rail
Output Type:
Transistor
Product Type:
Logic Controller
Battery Backup:
Yes
Output Current:
0.5A
Supply Voltage:
24V
Display Included:
Yes
Number of Inputs:
4
Program Capacity:
32MB
Number of Outputs:
4
Standards/Approvals:
ANSI/ISA 12-12-01, CSA C22.2 No 213, CSA C22.2 No 61010-1, CSA C22.2 No 61010-2-201, EN 61131-2, UL 61010-1, UL 61010-2-201
Better World Product:
Yes
Communication Port Type:
Ethernet/IP, HTTP, Modbus RTU, Modbus TCP, Serial Link, ASCII
Programming Language Used:
Sequential function chart (SFC), CFC, FBD, Instruction List (IL), Ladder Diagram, Structured Text (ST)
Maximum Operating Temperature:
60°C
Minimum Operating Temperature:
-20°C
