The RS PRO 773-9049 is a high-quality, heavy-duty power cable designed for demanding industrial environments. With a length of 100m, this power cable features three cores of bare stranded copper conductors, each insulated with Ethylene Propylene Rubber (EPR) and encased in a durable Chlorinated Polyethene (CPE) sheath. This construction provides excellent resistance to abrasion, oils, chemicals, and UV exposure, making it suitable for both indoor and outdoor applications. With a 450/750 voltage range and a maximum operating temperature of +60°C, it's ideal for powering equipment in construction sites, industrial machinery, and temporary installations.

Why Buy the RS PRO Power Cable?

Opting for the RS PRO 773-9049 cable ensures reliability and durability in challenging conditions. Its robust construction and high-quality materials reduce the risk of wear and tear, minimizing downtime and maintenance costs. The cable's flexibility and ease of installation save time and effort, while its compliance with European harmonized standards (H07RN-F) guarantees safety and performance.

Typical Applications of the RS PRO 773-9049 CPE Power Cable, 100m, 3 Core:

This versatile power cable is suitable for a wide range of applications requiring durable and flexible wiring solutions. Typical uses include:

  • Powering industrial equipment and machinery
  • Supplying electricity to construction sites and temporary installations
  • Connecting electrical tools and portable generators
  • Wiring for lighting systems in outdoor environments
  • Providing power in areas exposed to oils, chemicals, or UV radiation.

RS Pro , 3 Core CPE Black Power Cable, 100m

Manufacturer:
Manufacturer Part No:
773-9049
Enrgtech Part No:
ET13992994
Warranty:
Manufacturer
£ 366.96 £ 256.87
Checking for live stock
American Wire Gauge:
13 AWG
Current Rating:
25 A
Conductor Resistance:
7.98 Ω/km
Number of Cores:
3
CPR Certification:
Eca
Outer Diameter:
11.8mm
Number of Strands:
49
Standards Met:
VDE 0285-525-2-21
Core Strands:
49/0.24 mm
Conductor Strand Type:
Stranded
Maximum Operating Temperature:
+60°C
Cross Sectional Area:
2.5 mm²
Voltage Rating:
450 V, 750 V
Fire Behaviour:
Flame Retardant
Length:
100m
Sheath Material:
CPE
Conductor Material:
Copper
Size of Strands:
0.24 mm
Sheath Colour:
Black
Insulation Material:
EPR
Minimum Operating Temperature:
-25°C
European Harmonised Code:
H07RN-F
pdf icon
RS PRO Datasheet(Technical Reference)
pdf icon
Cable Selection Guide(Technical Reference)
pdf icon
RS PRO Wiring and Connectivity Selection Guide 2021(Technical Reference)
