Inductive proximity sensors (XS range) and capacitive proximity sensors (XT range) for non contact sensing of metal objects up to 60 mm. Best in class quality and immunity to harsh industrial environments. Inductive sensor XSD 80x80x40 - plastic - Sn60mm - 12..48VDC – terminals

Telemecanique Sensors Inductive Block Proximity Sensor, 60 mm Detection, PNP NO+NC, 12 → 48 V dc

Manufacturer:
Manufacturer Part No:
XSDH607339
Enrgtech Part No:
ET5006189
Warranty:
Manufacturer
Checking for live stock
Sensor Technology:
Inductive
Detection Range:
60 mm
Body Style:
Block
Output Function:
NO+NC
Digital Switching Output Type:
PNP
Connection Type:
Screw Terminal
Supply Voltage:
12 → 48 V dc
Length:
80mm
IP Rating:
IP67
Mounting Type:
Non-Flush
Width:
40mm
Housing Material:
Plastic
Maximum DC Voltage:
48V
Minimum Operating Temperature:
-25°C
Shielding:
Unshielded
Depth:
100mm
Short Circuit Overload Protection:
Yes
Switching Frequency:
50 Hz
Maximum Operating Temperature:
+70°C
Series:
OsiSense XS
Switching Current:
200 mA
Standards Met:
CCC Certificate
Maximum Switching Frequency:
50Hz
pdf icon
Datasheet XSDH607339-c9a1beb4(datasheets)
pdf icon
Packaging Machines Application Software-d8891ecf(datasheets)
pdf icon
Packaging Automation-7b0d4b94(datasheets)
pdf icon
Instruction_Sheet 1-8b1eb2c6(datasheets)
pdf icon
Instruction_Sheet 2-5d3694fd(datasheets)
pdf icon
Brochure-ebbefa57(datasheets)
