Modes:
Double Pulse, Function, Modulation, Noise, Pattern, Policy Based Routes, Pulse, Square, Sweep, Triggered, Arbitrary, Burst
Width:
250mm
Height:
97mm
Jitter:
30%
Length:
295mm
Weight:
3.2kg
Calibrated:
RSCAL
Product Type:
Pulse Generator
Interface Type:
USB, USB 2.0, LXI, Remote, GPIB, LAN
Input Impedance:
10kΩ
Rise - Fall Time:
799.99s
Maximum Frequency:
50MHz
Minimum Frequency:
1MHz
Maximum Pulse Delay:
999.99999998s (Pulse), 999.99999996s (Double Pulse)
Maximum Pulse Width:
499.99999999s (Double Pulse), 999.99999999s (Pulse)
Minimum Pulse Delay:
0ns
Minimum Pulse Width:
10ns
Standards/Approvals:
No
Adjustable Output Amplitude:
Yes
Maximum Operating Temperature:
40°C
Minimum Operating Temperature:
5°C
