Siemens Pushbutton
The Siemens SIRIUS ACT illuminated mushroom pushbutton has a 22mm mounting diameter with a round green body. The actuating element is made from a plastic material with a 60mm diameter. It has a metal, high gloss silver-coloured standard front ring.
Features and Benefits
• Compact in size
• Momentary contact actuator element
• Operating temperature ranges between -25°C and 70°C Applications • Factories
• Industries
• Power plants Certifications • CE certified
• CSA
• EAC
• IEC 60068-2-27
• IEC 60068-2-6
• IEC 60721
• IP66 rated
• IP67 rated
• IP69 rated
• IP69K rated
• NEMA 1, 2, 3, 3R, 4, 4X, 12, 13 rating
• UL listed
• Momentary contact actuator element
• Operating temperature ranges between -25°C and 70°C Applications • Factories
• Industries
• Power plants Certifications • CE certified
• CSA
• EAC
• IEC 60068-2-27
• IEC 60068-2-6
• IEC 60721
• IP66 rated
• IP67 rated
• IP69 rated
• IP69K rated
• NEMA 1, 2, 3, 3R, 4, 4X, 12, 13 rating
• UL listed
SIRIUS ACT 3SU10 Series Green Momentary Push Button, 22mm Cutout, IP66, IP67, IP69K
Manufacturer:
Siemens
Manufacturer Part No:
3SU1050-1CD40-0AA0
Enrgtech Part No:
ET17499148
Warranty:
Manufacturer
£ 11.06
Checking for live stock
Series:
SIRIUS ACT 3SU10
Cutout Diameter:
22mm
Push Button Colour:
Green
Push Button Actuation:
Momentary
Push Button Style:
Round
Push Button Material:
Metal
IP Rating:
IP66, IP67, IP69K
Push Button Diameter:
60mm
Better World Claim:
Extended product life, Low carbon manufacture
Better World Product:
Yes
3D Model:
https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=1812821&DisplayLogo=False
