he3621a0500 Wickmann PCB Mount Reed Relay, 5V dc Coil, SPST, 200V Max, 500 mA Max, 500Ω
he3621a0500 Wickmann PCB Mount Reed Relay, 5V dc Coil, SPST, 200V Max, 500 mA Max, 500Ω

Wickmann PCB Mount Reed Relay, 5V dc Coil, SPST, 200V Max, 500 mA Max, 500Ω

Wickmann PCB Mount Reed Relay, 5V dc Coil, SPST, 200V Max, 500 mA Max, 500Ω

Manufacturer:
Wickmann
Manufacturer Part No:
HE3621A0500
Enrgtech Part No:
ET100666181
Warranty:
Manufacturer
£ 1.40 £ 1.40
Checking for live stock
Contact Configuration:
SPST
Coil Voltage:
5V dc
Mounting Type:
PCB Mount
Maximum Switching Current DC:
500 mA
Maximum Switching Voltage DC:
200V
Coil Resistance:
500Ω
Length:
19.05mm
Height:
7.45mm
Depth:
5.08mm
Dimensions:
19.05 x 5.08 x 7.45mm
Isolation Coil To Contact:
1.5kV ac
Terminal Type:
PCB Pin
Contact Resistance:
150 mΩ
Number of Poles:
1
Maximum Switching Power DC:
10 W
Operating Temperature Range:
-40 → +85°C
Operating Time Including Bounce:
1ms
Special Features:
Diode Suppression Option, External Magnetic Shield Option, Normally Open Contact Version, Optional Coil Suppression Diode → Protect Coil Drive Circuits
Minimum Operating Temperature:
-40°C
Maximum Operating Temperature:
+85°C
pdf icon
0900766b81637b4d.pdf(datasheets)
