Coil Voltage:
12V dc
Contact Configuration:
SPST
Mounting Type:
Surface Mount
Maximum Switching Current DC:
3 A
Maximum Switching Voltage AC:
250V ac
Maximum Switching Voltage DC:
220V dc
Maximum Switching Power DC:
60 W
Series:
DS
Latching:
No
Length:
20mm
Depth:
9.9mm
Height:
9.4mm
Dimensions:
20 x 9.9 x 9.9mm
Terminal Type:
PCB Pin
Number of Poles:
1
Switching Current:
3A
Application:
General Purpose, Office Equipment, Safety, Telecommunications
Operating Temperature Range:
-40 → +70°C
Coil Resistance:
360Ω
Life:
10^7 (Mechanical) Operations, 5 x 10^5 (Electrical) Operations
Maximum Switching Power AC:
125VA
Coil Power:
400mW
Isolation Coil To Contact:
1.5kV rms
Maximum Operating Temperature:
+70°C
Electrical Life:
5000000 Operation Cycles
Minimum Operating Temperature:
-40°C
Contact Material:
Gold Plated
Features:
Suitable For Use In Difficult Environments, Gold Clad Twin Contacts Ensure High Reliability, Can Be Used With Automatic Solder And Automatic Wash Systems
