6715-bk005 Alpha Wire 18 AWG Hook-Up Wire 16/30 Black 600V

The Alpha Wire 6715-BK005 combines high-performance electrical reliability with an eco-conscious design tailored for global industries. Encased in halogen‑free modified polyphenylene ether (mPPE) insulation, this single‑conductor cable delivers excellent dielectric strength, operating from –40 °C to +105 °C at up to 600 V. It is ideal for diverse applications, from automation and control panels to telecommunications and instrumentation. Its durable, recyclable build ensures consistent performance across demanding environments while aligning with worldwide sustainability standards.

Why Should You Buy the Alpha Wire 18 AWG Hook-Up Wire, Black 600V?

The 6715‑BK005 stands apart due to its innovative mPPE insulation, which is non‑halogenated, free from heavy‑metal pigments, fully recyclable, and significantly lighter and thinner than traditional PVC alternatives, up to 45 % smaller in diameter and 40 % lighter. Certified to UL Style 11028 and rated at 600 V with –40 °C to +105 °C temperature resilience, it offers dependable electrical performance and safety across global installations.

Core Features and Benefits Include

Enhanced dielectric strength with advanced mPPE insulation.
Up to 45 % smaller diameter and 40 % lighter than PVC equivalents.
High voltage rating of 600 V and wide operating temperature span (–40 °C to +105 °C).
Halogen-free, recyclable, and free of heavy metal impurities, suits port global environmental standards like WEEE.
Compact and color‑coded (black shown; other color options available) for versatile wiring and easy identification.

Broad Range Application

Control cabinets and industrial automation wiring
Electrical instrumentation and measurement systems
Telecommunications and network equipment
Consumer electronics and appliance internal wiring
Aerospace, defense, and transportation power harnesses
Renewable energy and environmentally-regulation-conscious manufacturing

For more information please check the datasheets.

Alpha Wire 18 AWG Hook-Up Wire 16/30 Black 600V

Manufacturer:

Alpha Wire

Manufacturer Part No:

6715 BK005

Enrgtech Part No:

ET11390730

Warranty:

Manufacturer

£ 49.31 £ 34.52

Checking for live stock

Insulation Wall Thickness:

0.3mm

American Wire Gauge:

18 AWG

Number of Strands:

Standards Met:

CE, CSA, UL

Cable Shape:

Single Core

Conductor Material:

Copper

Series:

Ecogen Ecowire

Shield Type:

Unshielded

Voltage Rating:

600 V

Core Strands:

16/0.25 mm

Sheath Colour:

Black

Size of Strands:

0.25 mm

Datasheet(Technical Reference)

EcoGen Wire & Cable Brochure(Technical Reference)

Cable Selection Guide(Technical Reference)

Hook-Up Wire Catalog(Datasheets)
