C&K Slide Switch The C&K slide switch is a surface mount double pole double throw (DPDT) switch. It is a mechanical slider used to control current flow in a circuit. This is a latching switch with 300mA current rating and 9mm length. Features and Benefits • 3.5mm depth
• 500VAC dielectric strength
• Copper alloy and silver plate is used as contact material
• Less space required
• Service temperature ranges between -40°C and 85°C Applications • Telecommunication
• Computer peripherals
• Instrumentation
• Thermostat select switch

C & K Surface Mount Slide Switch DPDT Latching 300 mA Slide

Manufacturer:
Manufacturer Part No:
JS202011SCQN
Enrgtech Part No:
ET11778106
Warranty:
Manufacturer
Checking for live stock
Contact Configuration:
DPDT
Mounting Type:
Surface Mount
Switch Operation:
Latching
Contact Current Rating:
300 mA
Terminal Type:
Gull Wing
Actuator Type:
Slide
Length:
9mm
Width:
3mm
Depth:
5.5mm
Dimensions:
9 x 3 x 5.5mm
Contact Resistance:
70mΩ
Voltage Rating:
6V dc
Actuator Material:
Nylon
Operating Temperature Range:
-40 → +85°C
Minimum Operating Temperature:
-40°C
Maximum Operating Temperature:
+85°C
Contact Material:
Copper Alloy
pdf icon
Datasheet-d5c1c352(datasheets)
