New TeSys GV4 is a compact and robust motor circuit breaker, up to 115 A with 100 kA breaking capacity, available with 3 kinds of protection: magnetic, electronic thermal magnetic, electronic thermal magnetic with advanced protections and alarming designed for demanding applications.TeSys GV4 is also equiped with patented Everlink power connections, and may be equiped with a wide range of accessories, mainly: auxiliaries (1 OF, 1SD, 1 coil MN or MX), rotary handle (direct, front extended or side) and advanced alarming and fault differentiation module. b Magnetic GV4L: to be used with an overload relay or a drive b Thermal magnetic GV4P: electronic protection with wide range setting, dual class (10 & 20) b Multifunction motor protection GV4PEM: GV4P with adjustable advanced protections and possibility to have a side module SDx for alarming and fault differentiation.

Schneider Electric 80A 3P Pole Thermal Magnetic Circuit Breaker, 690V ac GV4P

Manufacturer:
Manufacturer Part No:
GV4P80N
Enrgtech Part No:
ET16930221
Warranty:
Manufacturer
£ 518.63
Checking for live stock
Better World Verification:
Green Premium
Better World Product:
Yes
Current Rating:
80A
Voltage Rating:
690V ac
Tripping Mechanism:
Thermal-Magnetic
Series:
GV4P
Circuit Breaker Type:
Thermal Magnetic Circuit Breaker
Overall Dimensions:
81 x 165 x 155mm
Breaking Capacity at Maximum Voltage Rating:
8 kA @ 660 → 690 V ac
Width:
165mm
Range:
TeSys
Rated AC Voltage:
690V
Overall Length:
81mm
Overall Depth:
155mm
Number of Poles:
3
pdf icon
Datasheet_GV4P80N(Technical Reference)
pdf icon
Product Environmental Profile(Technical Reference)
