The Festo ESH suction cup holder without height compensator, vacuum connection at top and compensator secured by two hexagonal nuts. The QS push-in connector vaccum port for suction cup mounting M4. Voulme = 0.52Cm3Assembly position = verticalCorrelation to suction-cup holder = size 3Operating medium = atmospheric air basedOn ISO 8573-1:2010 [7:-:-]

The Festo ESH suction cup holder with height compensator, vacuum connection at top and compensator secured by two hexagonal nuts. The barbed fitting connection PK for suction cup mounting 3mm. Voulme = 0.117Cm3Assembly position = verticalCorrelation to suction-cup holder = size 1

The Festo's suction cup is used without sealing ring which has nominal size 4mm and effective diameter is 67.4 mm. It has position of connection on top and assembled in any position. Ambient temperature -20 to 60 °CSuction cup height compensator 3.5 mm

Festo Elbow Threaded Adaptor, G 1/8 Male to Push-In 6mm, 20 Bar - NPQH-L-G18-Q6-P10 This adaptor from Festo is an efficient choice for connecting two conduits in your pneumatic system. Its standard G 1/8 threaded end twists tightly in place, while the other push-in end makes for a fast and easy connection. Once installed, the adaptor seals the pressurised air inside the system to ensure it operates effectively. As an elbow fitting, this component creates a 90° angle joint, so you can change the shape and direction of your system. • Compact and lightweight design that's easy to fit in awkward spaces• Operating temperature range of 0°C to +150°C for use with heated systems and in extreme conditions• Robust 2mm tubing wall for durability and longevity• Suitable for powerful pressure systems up to 20 bar Applications • Food industry• Industrial automation• Automotive industry How can I be sure this adaptor is safe for the food industry? The adaptor's brass body material, nickel-plating and FPM (fluorocarbon rubber) release ring are designed to fully maintain their structure and not be absorbed into food products. They won't reduce food quality when they come into contact and they don't make food equipment difficult to clean or sanitise.

The festo non-return valve HB-1/4-QS-8 Flow rate from the QS plug connector to the male thread. It has operating pressure –1 to 10 bar. The operating medium compressed air in accordance with ISO 8573­1:2010. The peration with lubricated medium possible (i Valve function Non-return functionPneumatic connection, port 1 QS-8Pneumatic connection, port 2 R1/4 Mounting type ThreadedStandard nominal flow rate 696 l/min

The Festo coupling socket NPHS-D6-P-G38F has Standard nominal flow rate=2083 l/min. Operating pressure complete temperature range=-0,95 - 10 bar Operating medium Compressed air in accordance with ISO8573-1:2010 [7:-:-] Note on operating and pilot medium Lubricated operation possible Corrosion resistance classification CRC 1 - Low corrosion stress

The push-in T-fitting NPQM-T-G14-Q10-P10 Attractively priced metal push-in fitting for pneumatic applications with a temperature range up to 70 °C and a pressure range up to 16 bar. Size Standard Nominal size 8,5 mm Type of seal on screw-in stud Sealing ring Design structure Push/pull principle Operating pressure complete temperature range -095 - 16 bar

The festo pressure indication OH-8-GN is actuated when a pressure of more than 18 psi / 1.2 bar is present. When the indicator is actuated, a colored sleeve extends into the transparent cap and can be seen from all sides. Operating pressure -1 - 8 bar Operating medium Compressed air in accordance with ISO8573-1:2010 [7:-:-] Note on operating and pilot medium Lubricated operation possible (subsequently required for further operation) Ambient temperature -10 - 60 °C Pneu

The Festo blanking plug has mini size which used QS-3 fitting of push-in sleeve. Ambient temperature -10 to 80 °CContainer size 10

MS Series Mounting Brackets The MS Series by Festo features a range of mounting brackets and accessories to suit the MS series of pneumatic filters and regulators.

Festo Pneumatic Cylinder, 10 Bar Maximum Operating Pressure, 10mm Stroke, ADN-50-10-I-P-A Looking for a high-quality and reliable pneumatic cylinder for your industrial automation system? Look no further than the Festo ADN-50-10-I-P-A. This top-of-the-line cylinder offers exceptional performance and durability, making it a smart choice for a wide range of industrial applications. This robust and reliable pneumatic cylinder is designed to work under pressure and meet the demands of a wide range of industrial automation applications. With its corrosion-resistant construction and integrated sensor slots, it is built to last and provide accurate and consistent performance. Features & Benefits Compact design for easy integration into tight spacesHigh-precision piston rod and adjustable cushioning for reduced shockIntegrated sensor slots allow for easy installation and monitoring of sensors Complies with ISO 21287 standard Applications Packaging machineryMaterial handling systemsAutomated manufacturing processesRobotics Can this cylinder be used in harsh environments? Yes, the corrosion-resistant construction of this cylinder makes it suitable for use in harsh environments.

The Festo compact cylinder is smaller systems yet better performance. This is a feat compact cylinders ADN-S are capable of. They are extremely small and light and deliver excellent performance with small movements. Variants recommended for production systems for manufacturing lithium-ion batteries, sustainable in production thanks to reduced use of materials. Minimal installation spaceVery lightweightIdeal for small movementsPiston rod with female or male threadFor position sensing
