dsPIC33F Digital Signal Controllers The dsPIC33F Digital Signal Controllers offer the performance of a DSP with the simplicity of an MCU. The 40MIPS dsPIC33F core is designed to execute digital filter algorithms, high-speed precision digital control loops and digital audio and speech processing.dsPIC33F DSCs with Motor Control peripherals enable the design of high-performance, precision motor control systems. The dsPIC33F SMPS DSCs provide on-chip peripherals specifically designed for high-performance, digital power supplies. SMPS peripherals include high speed and high resolution PWM, fast ADC and analogue comparators.

High-performance, 8-bit microcontroller with 32KB flash. It retains all features of the 80C52 with 256 Bytes of internal RAM, a 9-source 4-level interrupt controller, and three timer/counters. It features a programmable counter array, an XRAM of 1024 bytes, hardware watchdog timer, keyboard interface, SPI interface, versatile serial channel that facilitates multiprocessor communication (EUART), and a speed improvement mechanism (X2 mode).We recommend implementing an external brown-out to prevent any flash/EEPROM corruption during power-on or power-off.

Single-cycle microcontroller with 64KB ISP flash and 12-clock compatibility mode. It includes 4KB EEPROM data memory, 2304 bytes RAM, 2KB ROM with UART-based Bootloader, PWM, UART, TWI, SPI, PCA, up to 42 I/Os, 10-bit A/D, dual Analog Comparators, an internal 8 MHz RC oscillator, and on-chip debug. The TWI and On-Chip Debug features are not available on 40-pin PDIP package.

The Microchip PIC18-Q83 family expands the 8-bit MCUs by combining an extensive array of Core Independent Peripherals (CIPs) with Controller Area Network (CAN). These cost optimized MCUs contain time-saving CIPs in up to 48-pins with up to 128 KB of flash memory. Temperature Range (°C)-40 to 125Operating Voltage Range (V) 1.8 to 5.5Pin Count 28Low Power

The Microchip microcontrollers PIC16F range are 8-bit MCUs that incorporate Microchip’s PIC® architecture into a variety of pin and package options, from space efficient 14-pin devices to feature-rich 64-pin devices. Devices with Baseline, Mid-Range or Enhanced Mid-Range architecture are available with numerous different peripheral combinations, giving designers flexibility and choice for their applications. The PIC16F1824/1828 family of microcontrollers is based upon Microchip’s enhanced mid-range core with a 16 level deep hardware stack and 49 instructions. These MCUs provide up to 8 MIPS, 7 Kbytes program memory, 256 bytes RAM and Data EEPROM of 256 bytes. On board is a configurable oscillator with ±1% accuracy. Operating speed 35 MHz oscillator clock cycle125ns instruction cycleSleep mode 20 nAWatchdog timer 200nAOperating current48uA/MHz4X Phase Lock Loop (PLL)Operating voltage 1.8V - 5.5VProgrammable code protection5 bit rail-to-rail resistive DAC with positive and negative reference selection

A newer device is available. Please consider the PIC16F887. This powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS FLASH-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into an 40- or 44-pin package and is upwards compatible with the PIC16C5X, PIC12CXXX and PIC16C7X devices. High performance RISC CPU:Only 35 single word instructions to learnAll single cycle instructions except for program branches which are two cycleOperating speed: DC - 20MHz clock input:DC - 200 ns instruction cycleUp to 8K x 14 words of FLASH Program Memory, Up to 368 x 8 bytes of Data Memory (RAM)Up to 256 x 8 bytes of EEPROM Data MemoryPinout compatible to the PIC16C73B/74B/76/77Interrupt capability (up to 14 sources)Eight level deep hardware stackDirect, indirect and relative addressing modes

This powerful (200 nanosecond instruction execution) yet easy–to-program (only 35 single word instructions) CMOS Flash-based 8-bit microcontroller packs Microchip’s powerful PIC® architecture into an 18-pin package and is upwards compatible with the PIC16C7x, PIC16C62xA, PIC16C5X and PIC12CXXX devices. The PIC16F88 features 8 MHz internal oscillator, 256 bytes of EEPROM data memory, a capture/compare/PWM, an Addressable USART, a synchronous serial port that can be configured as either 3-wire Serial Peripheral Interface (SPI™) or the 2-wire Inter-Integrated Circuit (I²C™) bus, 7 channels of 10-bit Analog-to-Digital (A/D) converter and 2 Comparators that make it ideal for advantage analog / integrated level applications in automotive, industrial, appliances and consumer applications. 1 PWM 10-bit8 MHz Internal OscillatorICD256 bytes of EEPROM data memoryCapture/Compare

MCP7941x I²C Real-Time Clock/Calendars

PIC16F1825/1829 8-Bit Flash Microcontrollers The PIC16F range of microcontrollers from Microchip are 8-bit MCUs that incorporate Microchip’s PIC® architecture into a variety of pin and package options, from space efficient 14-pin devices to feature-rich 64-pin devices. Devices with Baseline, Mid-Range or Enhanced Mid-Range architecture are available with numerous different peripheral combinations, giving designers flexibility and choice for their applications.The PIC16F1825/1829 family of microcontrollers is based upon Microchip’s enhanced mid-range core with a 16 level deep hardware stack and 49 instructions. These MCUs provide up to 8 MIPS, 14 Kbytes program memory, 1024 bytes RAM and Data EEPROM of 256 bytes. On board is a configurable oscillator with ±1% accuracy. Microcontroller Features 32 MHz Max. CPU Speed49 Instructions16 Level Hardware Stack32 MHz Internal Oscillator – Selectable Frequency Range 32 MHz to 31 kHz12 I/O Pins – PIC16F182518 I/O Pins – PIC16F1829XLP TechnologyPower-On Reset (POR)Power-Up Timer (PWRT)Oscillator Start-Up Timer (OST)Brown-Out Reset (BOR)Extended Watchdog Timer (WDT)Enhanced Low-Voltage Programming (LVP)In-Circuit Serial Programming (ICSP)In-Circuit Debug (ICD) Peripherals 10-bit Analogue to Digital Converter (ADC) – PIC16F1825 8 Channels, PIC16F1829 12 ChannelsmTouchTM Capacitive Sensor Module – PIC16F1825 8 Channels, PIC16F1829 12 ChannelsTwo Capture/Compare/PWM (CCP) ModulesTwo Enhanced Capture/Compare/PWM (ECCP) ModulesTwo ComparatorsFour 8-bit TimersOne 16-bit TimerMaster Synchronous Serial Port (MSSP) with SPI and I2C – PIC16F1825 x 1, PIC16F1829 x 2Enhanced Universal Synchronous Asynchronous Receiver Transmitter (EUSART)Fixed Voltage Reference (FVR)SR Latch

PIC18F1xK22 8-Bit Flash Microcontrollers The PIC18F2x1x/4x1x family of microcontrollers are based on PIC18 architecture that offers a 31 level hardware stack and 75 instructions. These MCUs feature eXtreme Low Power technology, ideal for applications where low power consumption is vital. Microcontroller Features 16 MIPS Max. CPU Speed75 Instructions – 83 with Extended Instruction Set Enabled31 Level Hardware StackConfigurable Internal Oscillator – Selectable Frequency Range 16 MHz to 31 kHz18 I/O PinsPower-On Reset (POR)Power-Up Timer (PWRT)Oscillator Start-Up Timer (OST)Brown-Out Reset (BOR)Extended Watchdog Timer (WDT)In-Circuit Serial Programming (ICSP)In-Circuit Debug (ICD) eXtreme Low-Power Features Sleep Mode: 34 nAWatchdog Timer: 460 nATimer1 Oscillator: 650 nA @ 32 kHz Peripherals 10-bit Analogue-to-Digital Converter (ADC) – 12 ChannelsComparator ModuleVoltage Reference ModuleThree 16-bit TimersOne 8-bit TimerOne Enhanced Capture, Compare, PWM ModuleMaster Synchronous Serial Port (MSSP) Module with SPI and I²CEnhanced Addressable Universal Synchronous Asynchronous Receiver Transmitter (EUSART)SR Latch Module

MCU Core:80MHz/105DMIPS, 32-bit MIPS M4K® CoreUSB 2.0 On-The-Go Peripheral with integrated PHY10/100 Ethernet MAC with MII/RMII Interfaces2 x CAN2.0b modules with 1024 buffers8 Dedicated DMA Channels for USB OTG, Ethernet, and CAN5 Stage pipeline, Harvard architectureMIPS16e mode for up to 40% smaller code sizeSingle cycle multiply and hardware divide unit32 x 32-bit Core Registers32 x 32-bit Shadow RegistersFast context switch and interrupt response MCU System Features:512K Flash (plus 12K boot Flash)128K RAM (can execute from RAM)8 Channel General Hardware DMA ControllerFlash prefetch module with 256 Byte cacheLock instructions or data in cache for fast accessProgrammable vector interrupt controller

PIC16F818/819 8-Bit Microcontrollers The PIC16F range of microcontrollers from Microchip are 8-bit MCUs that incorporate Microchip’s PIC® architecture into a variety of pin and package options, from space efficient 14-pin devices to feature-rich 64-pin devices. Devices with Baseline, Mid-Range or Enhanced Mid-Range architecture are available with numerous different peripheral combinations, giving designers flexibility and choice for their applications.The PIC16F818/819 family of microcontrollers is based upon Microchip’s Mid-Range core with an 8 level deep hardware stack and 35 instructions. These MCUs provide up to 5 MIPS, up to 14 Kbytes program memory and 368 bytes RAM. On board is a configurable oscillator factory calibrated to ±1% accuracy. Microcontroller Features 20 MHz Max. CPU Speed35 Instructions8 Level Hardware Stack8 MHz Internal Oscillator – Selectable Frequencies 8 MHz to 31 kHz16 I/O PinsPower-On Reset (POR)Brown-Out Reset (BOR)Power-Up Timer (PWRT)Oscillator Start-Up Timer (OST)Watchdog Timer (WDT)In-Circuit Serial Programming (ICSP)In-Circuit Debug (ICD) Peripherals 5 Channel 10-bit Analogue-to-Digital Converter (ADC)Capture, Compare, PWM (CCP) ModuleTwo 8-bit TimersOne 16-bit TimerSynchronous Serial Port (SSP) with SPI and I2C
