PULS Redundant DIN Rail Power Supply The PULS Dimensions CP-series single output DIN-rail redundant power supply has an output current rating of 20A at 24VDC. It has a single-phase input voltage ranging between 100VAC and 240VAC/ 110VDC and 150VDC with integrated decoupling function. These units include a decoupling MOSFET for building 1+1 or n+1 redundant power supply systems without the need for external redundancy modules. These are cost optimised power supplies specifically designed with uncompromised quality and reliability for high-performance. The most outstanding features of these units are of small size and high-efficiency. The power supplies can deliver three times the nominal output current for 12ms that helps to trip fuses on faulty output branches. High immunity makes it suitable for almost every situation. Features and Benefits 20% output power reserves<BR/>Active power factor correction (PFC)<BR/>Efficiency up to 95.2%<BR/>Excellent partial load efficiency<BR/>Minimal inrush current surge<BR/>Operation temperature ranging between -40°C and 70°C<BR/>Power rating is 480W<BR/>Ripple factor and noise is 50mV<BR/>Safe HiccupPLUS overload mode Applications Communication and instrumentation equipment<BR/>Industrial control<BR/>Office Certifications ATEX certified<BR/>CE certified<BR/>cSAus listed<BR/>cULus listed<BR/>GL<BR/>IECEE<BR/>IECEX certified

The YR20.242 is a redundancy module, which can be used to build 1+1 and N+1 redundant systems. It is equipped with two input channels, which can be connected to power supplies with up to 24A output current and one output, which can carry nominal currents up to 24A. In addition to the YR20.242, the YR20.246 is available which is featured with an automated load sharing between the connected power supplies and functions which monitor defects in the redundancy circuit or too high output currents, which could prevent redundancy, if one power supply fails. For N+1 and 1+1 Redundant Systems<BR/>Dual Input with Single Output<BR/>Only 60mV Voltage Drop at 10A Output Current<BR/>Only 0.6W Loss at 10A<BR/>160% (32.5A) Peak Load Capability<BR/>Reverse Input Polarity Protection<BR/>Full Power Between -40°C and +70°C<BR/>Width only 32mm<BR/>Rugged Metal Housing<BR/>Easy Wiring: Distribution Terminal for Negative Pole Included

The YR20.242 is a redundancy module, which can be used to build 1+1 and N+1 redundant systems. It is equipped with two input channels, which can be connected to power supplies with up to 24A output current and one output, which can carry nominal currents up to 24A. In addition to the YR20.242, the YR20.246 is available which is featured with an automated load sharing between the connected power supplies and functions which monitor defects in the redundancy circuit or too high output currents, which could prevent redundancy, if one power supply fails. For N+1 and 1+1 Redundant Systems<BR/>Dual Input with Single Output<BR/>Only 60mV Voltage Drop at 10A Output Current<BR/>Only 0.6W Loss at 10A<BR/>160% (32.5A) Peak Load Capability<BR/>Reverse Input Polarity Protection<BR/>Full Power Between -40°C and +70°C<BR/>Width only 32mm<BR/>Rugged Metal Housing<BR/>Easy Wiring: Distribution Terminal for Negative Pole Included

PULS Buffer Module The PULS UF series buffer module has service free electrolytic capacitors. The Buffer units can be connected in parallel to increase the output capacity or the hold-up time. It is easy to install and does not need a control wiring. Features and Benefits Buffering of 24V load<BR/>Buffer time is 0.2 seconds at 20A (24V)<BR/>Clear status indication by status LED and signal outputs<BR/>Constant output voltage in buffer mode<BR/>Longer hold-up time at lower levels<BR/>Quick connect spring clamp terminals<BR/>The buffer units can be added in parallel to the load circuit at any given point Certifications CRUus certified<BR/>CE certified<BR/>EN approved<BR/>IEC 60950-1<BR/>SELV approved<BR/>UL 508 approved<BR/>CULus approved<BR/>UL 60950-1 approved

Dimension U-Series, Buffer Units Buffering with service free electrolytic capacitors<BR/>24V or 48V models available<BR/>Constant output voltage in buffer mode<BR/>Buffer time 0.2s at 20A (24V) or 0.1s at 20A (48V)<BR/>Longer hold-up time at lower levels<BR/>Buffer units can be connected in parallel to increase the output capacity or the hold-up time<BR/>Easy to install, no need for control wiring. The buffer units can be added in parallel to the load circuit at any given point<BR/>Clear status indication by status LED and signal outputs<BR/>Quick connect spring clamp terminals

PULS Dimension UPS The PULS uninterruptible power supply (UPS) controller UB10.241 is an addition to standard 24V power supplies to bridge power failures or voltage fluctuations. This device avoids expensive downtimes, long restart cycles, and loss of data. The DC-UPS includes a professional battery management system that charges and monitors the battery to achieve the longest battery service life, as well as, many diagnostic functions that ensure the reliable operation of the entire system. A unique feature of the UB10.241 is it requires only one 12V battery to buffer the 24V output. This makes matching batteries unnecessary and allows precise battery charging and testing. The UB10.241 comes with two preassembled battery modules for the external 12V battery, a lightweight 7Ah battery that can be mounted on the DIN-Rail, and a 26Ah module that can be panel mounted for longer buffer times. Features and Benefits 50% power reserves <BR/>Comprehensive diagnostic and monitoring functions <BR/>Current rating is 10A<BR/>Electronically overload and short circuit protected <BR/>Input voltage is 22.5VDC to 30VDC<BR/>Output voltage is 22.4VDC<BR/>Power rating is 240W<BR/>Replace battery signal included <BR/>Selectable buffer time limiter<BR/>Stable output voltage in buffer mode <BR/>Superior battery management for longest battery life Applications Communication<BR/>Industrial control<BR/>Instrumentation equipment<BR/>Office Certifications IEC 60950-1 standards<BR/>UL 508 standards<BR/>UL 60950-1 standards

YR2.DIODE DC12-48 V, 20 A, Dual Redundancy Module Dual diode redundancy module for building 1+1 and N +1 redundant power supply systems. It has two input channels which can be connected to 10 A power supplies and one output which can carry nominal currents up to 20 A. The YR2.DIODE is an excellent choice for use in a redundant system if the power supply is equipped with a DC-OK signal. Features and Benefits • Two 10 A inputs, one output (20A max.)<BR/>• Only 0.85 V voltage drop between input and output under full load<BR/>• Full output current between -40 °C and 60°C<BR/>• Quick connect spring-clamp terminals<BR/>• Reverse polarity protected input<BR/>• DC 12 V to 48 V, 20A output<BR/>• DC 12 V dc to 48 V dc (±25%) input<BR/>• Size: 32 x 124 x 102 mm (W x H x D)<BR/>• Weight 290 g Product Application Information A possible application for the diode is to use it to isolate sensitive load circuits with or without alarm signals. This avoids distortion of the power quality which can cause controller failures.

PULS DIN Rail Power Supply The PULS DIMENSION C-Line series single-phase DIN-rail switch-mode power supply has an output voltage of 48VDC at 5A current. This cost-optimised power supply is specifically designed with uncompromised quality and reliability for high-performance. The auto-select input voltage rating ranging between 100VAC and 120VAC/200VAC and 240VAC. This power supply has a specified life expectancy of the electrolytic capacitor of 50,000 hours. It has high immunity to power surges as well as low electromagnetic emission<BR/>Note:<BR/>Power de-rating between 60°C and 70°C Features and Benefits Slim design<BR/>20% output power reserves up to 45°C continuously allowed<BR/>Wide range auto select input<BR/>High efficiency is up to 91.6%<BR/>Power rating is 240W<BR/>Ripple factor and noise is 100mVpp<BR/>Excellent partial load efficiency<BR/>Minimal inrush current surge<BR/>Easy fuse breaking due to high overload peak current<BR/>Large screw terminals<BR/>Operation temperature ranges between -25°C and 70°C Applications Industrial control<BR/>Office<BR/>Communication and instrumentation equipment Certifications IEC<BR/>UL approved<BR/>EN<BR/>SELV<BR/>EAC<BR/>GL<BR/>CE certified

PULS DIN Rail Power Supply The PULS DIMENSION C-Line series single-phase DIN-rail switch-mode power supply has an output voltage of 24VDC at 10A current. This cost-optimised power supply is specifically designed with uncompromised quality and reliability for high-performance. The auto-select input voltage rating ranging between 100VAC and 120VAC/200VAC and 240VAC. This power supply has a specified life expectancy of the electrolytic capacitor of 50,000 hours. It has high immunity to power surges as well as low electromagnetic emission.<BR/>Note:<BR/>Power de-rating between 60°C and 70°C Features and Benefits Slim design<BR/>20% output power reserves up to 45°C is continuously allowed<BR/>Wide range auto select input<BR/>High efficiency up to 91.6%<BR/>Power rating is 240W<BR/>Ripple factor and noise is 50mVpp<BR/>Excellent partial load efficiency<BR/>Minimal inrush current surge<BR/>Easy fuse breaking due to high overload peak current<BR/>Large screw terminals<BR/>Operation temperature ranges between -25°C and 70°C Applications Industrial control<BR/>Automation<BR/>Communication and instrumentation equipment Certifications IEC<BR/>UL approved<BR/>EN<BR/>SELV<BR/>EAC<BR/>GL<BR/>CE certified

Dimension C-Series - Puls Power Supplies The C-Series DIN Rail power supplies are affordable basic units which offer an alternative to the feature-rich Q-Series. The same standards apply to the C-Series Puls power supplies as to all other PULS products in terms of quality. They are reliable, easy to operate, have a small overall size and generous power reserves. In the 120W class, the C-Series power supplies are even smaller than the Q Series and yet are every bit as durable. This power supply has a specified life expectancy of the electrolytic capacitor of 50,000 hours. The guaranteed power boost of +20% of the rated power is intended to ensure optimal adaptation to fluctuating loads. If the ambient temperature remains below 45°C or with forced ventilation, this performance is even specified for continuous loads. The units are equipped with automatic 115/230 V range switching for increased ease of operation and fault avoidance.<BR/>The units are available in special regional versions that cover either the 100 V to 120 V or 200 V to 240 V ranges. The C series Puls power supply supports regional applications and offers extra cost savings without sacrificing functionality. Features and Benefits • Wide range auto select input • Minimal inrush current • 20% Power reserves up to 45°C continuously allowed • Large screw terminals • CS10.242 has power factor correction to EN61000-3-2 • DC-ok LED • Cost effective

PULS DIN Rail Power Supply The PULS DIMENSION C-Line series single-phase DIN-rail switch-mode power supply has an output voltage of 24VDC at 5A current. This cost-optimised power supply is specifically designed with uncompromised quality and reliability for high-performance. The auto-select input voltage rating ranging between 100VAC and 120VAC/200VAC and 240VAC. This power supply has a specified life expectancy of the electrolytic capacitor of 50,000 hours. It has high immunity to power surges as well as low electromagnetic emission<BR/>Note:<BR/>Power de-rating between 60°C and 70°C Features and Benefits Slim design<BR/>20% output power reserves up to 45°C is continuously allowed<BR/>Wide range auto select input<BR/>High efficiency is up to 90.2%<BR/>Power rating is 120W<BR/>Ripple factor and noise is 50mVpp<BR/>Excellent partial load efficiency<BR/>Minimal inrush current surge<BR/>Easy fuse breaking due to high overload peak current<BR/>Operation temperature ranges between -25°C and 60°C Applications Industrial control<BR/>Automation<BR/>Communication and instrumentation equipment Certifications IEC<BR/>UL approved<BR/>EN<BR/>SELV<BR/>EAC<BR/>GL<BR/>CE certified

PULS DIN Rail Power Supply The PULS DIMENSION Q series single-phase DIN-rail switch-mode power supply has an adjustable output voltage ranging between 24VDC and 28VDC with 3.4A current. This cost-optimised power supply is specifically designed with uncompromised quality and reliability for high-performance. This unit is equipped with an input voltage ranging between 100VAC and 240VAC. This power supplies diagnostic is easy due to the dry DC-ok contact, a green DC-ok LED and red overload LED. High immunity to transients and power surges as well as low electromagnetic emission make it usable in nearly every environment. Features and Benefits Light and compact<BR/>Easy to install <BR/>Quick-connect spring-clamp terminals<BR/>Efficiency is up to 90%<BR/>Power rating is 80W<BR/>Ripple factor and noise is 50mVpp<BR/>Negligible low inrush current surge <BR/>150% peak load capability<BR/>DC-OK signal with relay <BR/>Operation temperature ranges between -25°C and 70°C Applications Industrial control<BR/>Automation<BR/>Communication and instrumentation equipment Certifications IEC<BR/>UL approved<BR/>EN<BR/>SELV<BR/>CE certified<BR/>GL
