TE Connectivity Non-latching Relay
The TE Connectivity BDS-A series flange mount automotive non-latching relay has a contact configuration of SPNO. It is actuated with 12VDC coil voltage and 190A switching current.
Features and Benefits
Coil resistance is 4.7ohm
Electrically settable and resettable ON/OFF bi-stable device
High peak current carrying capability is up to 1500A
Limiting continuous current 190A at 85°C
Suitable for voltage levels up to 42V Applications Coil suppression circuits
Cooling fan circuits
Wiper circuits Certifications ANSI/ESD S20.20:2014
BS EN 61340-5-1:2007
IP54 rated
Electrically settable and resettable ON/OFF bi-stable device
High peak current carrying capability is up to 1500A
Limiting continuous current 190A at 85°C
Suitable for voltage levels up to 42V Applications Coil suppression circuits
Cooling fan circuits
Wiper circuits Certifications ANSI/ESD S20.20:2014
BS EN 61340-5-1:2007
IP54 rated
Flange Mount Automotive Relay, 12V dc Coil Voltage, 190A Switching Current, SPST
Manufacturer:
TE Connectivity
Manufacturer Part No:
V23130C2021A412 1-1414939-4
Enrgtech Part No:
ET13832982
Warranty:
Manufacturer
£ 64.60
Checking for live stock
Coil Voltage:
12V dc
Coil Power:
7W
Coil Resistance:
4.7Ω
Contact Configuration:
SPST
Number of Poles:
1
Switching Current:
190A
Maximum Switching Voltage DC:
12V dc
Mounting Type:
Flange Mount
Terminal Type:
Screw
Height:
33mm
Isolation Coil To Contact:
500V rms
Length:
83mm
