MCP2515-e/ST, CAN Controller 1Mbps CAN 2.0B, 20-Pin TSSOP

Maximum Data Rate:

1Mbps

Number of Transceivers:

1

Standard Supported:

CAN 2.0B

IC Type:

CAN Controller IC

Power Down Mode:

Sleep, Standby

Maximum Supply Current:

10 mA

Mounting Type:

Surface Mount

Package Type:

TSSOP

Pin Count:

20

Dimensions:

6.5 x 4.4 x 0.9mm

Length:

6.5mm

Width:

4.4mm

Height:

0.9mm

Maximum Operating Supply Voltage:

5.5 V

Minimum Operating Supply Voltage:

2.7 V

Maximum Operating Temperature:

+125 °C

Minimum Operating Temperature:

-40 °C
