TIMER click mikroBUS™
TIMER click is a mikroBUS add-on board for recording Elapsed-Time. It features the Maxim DS1682, a Total-Elapsed-Time Recorder with Alarm. A 32-Bit Elapsed Time Counter monitors the event duration with a Quarter of a Second resolution. The TIMER click records the total time that the event input has been active, and the number of events that have occurred.
Programmable Elapsed Time Alarm output (Active-Low or High Impedance)
Event Input (Active high)
EEPROM maintains timer user data (10 Bytes) without power supply
I²C Bus interface on mikroBUS socket
3.3 V (default) or 5 V power supply on mikroBUS socket
Dimensions 28.6 x 25.4 mm
Event Input (Active high)
EEPROM maintains timer user data (10 Bytes) without power supply
I²C Bus interface on mikroBUS socket
3.3 V (default) or 5 V power supply on mikroBUS socket
Dimensions 28.6 x 25.4 mm
MIKROE-2333, TIMER Elapsed Time Counter mikroBus Click Board for DS1682
Manufacturer:
MikroElektronikaManufacturer Part No:
MIKROE-2333
Enrgtech Part No:
ET11747402
Warranty:
Manufacturer
£ 15.39
Checking for live stock
Clock/Timer Function:
Elapsed Time Counter
Kit Classification:
mikroBus Click Board
Featured Device:
DS1682
Kit Name:
TIMER
