MikroElektronika MCU Development Board The MikroElektronika MCU is a compact board designed for fast development on custom designs. This development board is based on the CY8C6347BZI-BLD53 microcontroller (MCU). This device belongs to the family of Arm Cortex based, dual-core, 32-bit MCUs. It can be either battery-powered or via USB. It works with a 3.7V Li-Po battery or a 5V USB cable via the mini-B USB port onboard. It uses a PSoC Creator IDE or standalone PSoC programmer software application for programming. This board has an exciting and flexible functionality that is ideal for designing portable devices. Features and Benefits: • Antenna: Bluetooth 2.4GHz• Audio: Audio subsystem, including two PDM channels and I2S interface• Bluetooth: BLE (Bluetooth Smart) BT 5.0 subsystem, including programmable output power energy Profiler block• Capacitive touch: CapSense technology• GPIO: 78 x pins with configuration options• MCU speed: 150MHz (M4 core) and 100MHz (M0 core)• Memory: 1MB application flash with 32kb EEPROM area and 32kb secure flash• Memory: 1MB application flash, 32kb secure flash, 32kb EEPROM• Oscillator: 32MHz crystal• PLBs: 12 x programmable logic blocks with 8 x Macrocells and an 8-bit data path (UDBs)• Programmer: KitProg2 PSoC programmer• SCB: 9 x serial communication blocks (configurable as I2C, SPI or UART)• USB: 1 x Mini-B USB port (for power) Applications: • Electronics laboratories• Embedded systems• IoT systems Certifications: • ANSI/ESD S20.20:2014• BS EN 61340-5-1:2007

ADC 8 Click is a high precision, low-power, 16-bit analog-to-digital converter (ADC), based around the ADS1115 IC. It is capable of sampling signals on four single-ended or two differential input channels. Although the ADS1115 cannot use an external reference, it incorporates a low-drift programmable voltage reference, along with the programmable gain amplifier (PGA). This allows for great flexibility in terms of the input signal level: it can sample signals from ±256 mV, up to 6.144 V, allowing a very high precision for a wide range of input signals, making it an excellent choice for various instrumentation applications.ADC 8 Click is supported by a mikroSDK compliant library, which includes functions that simplify software development. This Click board™ comes as a fully tested product, ready to be used on a system equipped with the mikroBUS™ socket.

MP3 click mikroBUS™ The Click accessory modules plug into the MikroBUS sockets in MikroElektronika microcontroller development boards. MP3 Click includes a stereo MP3 decoder chip which can decode multiple formats and encode three different formats from a microphone in mono or stereo format. VS1053 MP3 stereo CODECDecoder formats: Ogg vorbis, MP3, MP1, MP2, MPEG4, WMA, FLAC, WAV, MIDIEncoder formats: Ogg vorbis, IMA ADPCM, 16-bit PCMStereo headphone & microphone 3.5mm socketsCommunication: serial SPIPower supply +3.3Vdc

The MikroElektronika Step Up 2 Click is a compact add-on board designed to boost the power capabilities of devices. This board features the TPS61299, a synchronous boost converter from Texas Instruments. This component is renowned for its low quiescent current and high efficiency under light-load conditions. The board distinguishes itself with the ability to adjust output voltage via the integrated MAX5419 digital potentiometer, offering precise control through an I2C interface. It supports external voltages from 0.2V to 5.5V, delivering a regulated output range of 1.8V to 5.5V. Compatibility with 3.3V or 5V logic levels, selectable via the VCC SEL jumper, makes it useful for various MCUs. This Click board finds its application in powering devices that rely on alkaline or coin cell batteries, making it perfect for portable electronics.wearables, and small-scale IoT devices. Adjustable output voltageUltra-low quiescent currentHigh efficiencyFast transient performanceLow power consumption,Logic for MCU compatibility

The MikroElektronika I2C extend 2 click is a compact add-on board suitable for I2C communication bus extension, and it is supported by a mikroSDK compliant library, which includes functions that simplify software development. Low power consumptionImproved resistance to system noiseHot swap

RELAY click mikroBUS™ The Click accessory modules plug into the MikroBUS sockets in MikroElektronika microcontroller development boards. The RELAY Click board features two power PCB relay modules 2 x G6D1AASI-5DC power PCB relaysContact rating: 5A @ 250Vac or 5A @ 30VdcRelay coils transistor-driven from MikroBUS PWM (RL1) and CS (RL2) pinsRelay closed indicator LEDsPower on LEDPower supply: +5VdcScrew terminals

This GPS&GLONASS External Antenna is an excellent choice for all GPS/GLONASS Click boards™ from our offer. With its high gain, active band filtering, and magnetized base for easy installation, it is a perfect choice when reinforced positioning is required.

The MikroElektronika UPS 3 Click is a compact add-on board that represents a bidirectional active charge/balancing solution. This board features the LTC3110, a bidirectional buck-boost DC/DC regulator/charger combination with selectable operation modes for charging and system backup from Analog Devices. Type Battery chargerInterface GPIO

This multiband LTE Rubber Antenna with adjustable angle is an excellent choice for all 3G/4G LTE-based click boards from our offer, as well as other devices that require excellent throughput on all major cellular bands worldwide. The antenna has an SMA male connector on its end, which allows it to be mounted directly on the Click board™ or the female SMA module connector. The antenna position can be adjusted in 45⁰ increments (0⁰/45⁰/90⁰)

The MikroElektronika DIGI POT 6 Click features the MCP41HVX1 family of devices which have dual power rails (analogue and digital). The analogue power rail allows high voltage on the resistor network terminal pins. The analogue voltage range is determined by the V+ and V- voltages. 7/8-bit single digital potentiometer, +36V (±18V) maximum voltage on terminals, SPI communication protocol, low wiper resistanceInterface SPICompatibility microbusClick board size M (42.9 x 25.4 mm)Input Voltage 3.3V or 5V

The MikroElektronika Stepper 14 Click is a Click board™ that features the DRV8847PWPR, a step motor driver, from Texas Instruments. This Click board™ provides a bipolar step motor control, It features an H-bridge bipolar step motor driver, which supports full-, half-, quarter-, or eighth-step modes. Interface GPIO,I2CCompatibility microbusClick board size M (42.9 x 25.4 mm)Input Voltage 3.3V or 5V

The MikroElektronika TFT display module supports up to 24-bit pixel format (RGB: 888), allowing a true-colour palette of 16,7 million colours, and resolution of 800 x 480 pixels. It features an excellent contrast ratio and uniform brightness. This module is composed of a TFT-LCD panel, driver IC, FPC, a back light unit. Type TFTDisplay size 5"Resolution 800x480pxGraphic controller NoneTouch Screen Capacitive
