The WAGO potential multiplication module provides multiple tapping of the supply voltage. This module eliminates the need for additional rail-mount terminal blocks. Housing material polycarbonate and polyamide 6.6
Weight 43.5 g

WAGO Distribution Block, 8 Way, 0.08 → 2.5mm², 10A, 230 V ac/dc, Light Grey

Manufacturer:
Manufacturer Part No:
750-614
Enrgtech Part No:
ET28279746
Warranty:
Manufacturer
Checking for live stock
Number of Ways:
8
Termination Method:
Cage Clamp
Wire Size:
28 → 14 AWG
Housing Material:
Polyamide, Polycarbonate
IP Rating:
IP20
Current Rating:
10A
Voltage Rating:
230 V ac/dc
Cable CSA:
0.08 → 2.5mm²
Colour:
Light Grey
pdf icon
Datasheet - 750-614-ceb8a147(datasheets)
