3 Phase Backlit LCD Energy Meter

Series:

Countis E43

Display Type:

Backlit LCD

Number of Digits:

8

Number of Phases:

3

Depth:

64mm

Meter Accuracy:

Class 1 (IEC 62053-21), Class 2 (IEC 62053-22), Class C (EN 50470)

Minimum Temperature:

-25°C

Maximum Temperature:

+55°C

Maximum Measurement:

240 V, 12000 A

Minimum Measurement:

1 A, 230 V

Measurement Range:

1 To 12000 A (Current), 230 To 240 V (Voltage)

3D Model:

https://www.traceparts.com/els/rs-components/en/api/viewer/3d?SupplierID=RS_COMPONENTS&PartNumber=1925285&DisplayLogo=False
