Series:
SiliVolt-1V
Voltage:
1.5kV
Cable Length:
25m
Core Strands:
511
Product Type:
Hook Up Wire
Jacket Colour:
Red
Fire Behaviour:
CPR, Flame Retardant, Low Smoke Halogen Free, Oil Resistant, RoHS Compliant
Outside Diameter:
3.9mm
Conductor Material:
Copper
Standards/Approvals:
ISO9001, IEC60332-1, Mil Spec, REACH, RoHS, TS 9760 HD 21.5.S3, UL, UL1581 VW-1, VD0281-5, VD0292, BS4109, BASEC, IEC 60228 Css 5, IEC 60227-5, HAR, DEF STAN, Cmarked, CENELEC HD21.5, IEC60332-1-2, VD2050, BS4808, BS EN13062, VD0295
Maximum Operating Temperature:
150°C
Minimum Operating Temperature:
-50°C
