Voltage:
1.5kV
Cable Length:
25m
Core Strands:
651
Product Type:
Hook Up Wire
Jacket Colour:
Black
Fire Behaviour:
CPR, Flame Retardant, Low Smoke Halogen Free, RoHS Compliant
Outside Diameter:
3.9mm
Conductor Material:
Tinned Copper
American Wire Gauge:
14AWG
Standards/Approvals:
H05V-K, BASEC, BS4109, BS4808, BS EN13062, CENELEC HD21.5, CSA TEW, DEF STAN 61-12 Part 6, H05V2-K, H07V2-K, H07V-K, H07Z-K, HAR, IEC 60227-5, IEC 60228 Css 5, IEC60332-1, ISO9001, Mil Spec, REACH, RoHS, TS 9760 HD 21.5.S3, UL1007, UL1015, UL1213, UL1581 VW-1, VD0281-5, VD0295, VD2050
Maximum Operating Temperature:
70°C
Minimum Operating Temperature:
-10°C
