Series:
SiliStrom
Voltage:
1.5kV
Sub Type:
SILI-S 16.0
Cable Length:
10m
Core Strands:
4116
Product Type:
Hook Up Wire
Jacket Colour:
Black, Blue, Brown, Green, Grey, Orange, Pink, Red, Violet, White, Yellow
Fire Behaviour:
Flame Resistant, Flame Retardant, Low Smoke Halogen Free
Jacket Material:
ETFE, Ethylene Propylene Rubber, Fluorinated Ethylene Propylene, Polyalkene, Polyethylene, Polyethylene Terephthalate, Polytetrafluoroethylene, Polyvinyl Chloride, Rubber
Outside Diameter:
10.5mm
Conductor Material:
Copper
Standards/Approvals:
VDE 0295 part 5, BASEC, BS4109, BS4808, BS EN13062, CE, CENELEC HD21.5, DEF STAN 61-12, DIN VDE 0292, H05V2-K, H05V-K, H07V2-K, H07V-K, H07Z-K, HAR, HD 361, IEC 60227-5, IEC 60228 Class 5, IEC60332-1, IEC 60332-1-2, ISO9001, REACH, RoHS, TS 9760 HD 21.5.S3, UL, UL1581 VW-1, VDE 0281-5, VDE 2050
Maximum Operating Temperature:
150°C
Minimum Operating Temperature:
-50°C
