Series:
SiliVolt-2V
Voltage:
1.5kV
Sub Type:
Sili-2V 1.0
Cable Length:
25m
Core Strands:
511
Product Type:
Hook Up Wire
Jacket Colour:
Red
Fire Behaviour:
CPR, Fire Resistant, Flame Resistant, Flame Retardant, Low Smoke Halogen Free
Outside Diameter:
3.9mm
Conductor Material:
Copper
Standards/Approvals:
DIN 47100, H05V2-K, VD2050, VD0295, BASEC, BS4109, BS4808, BS EN13062, CE, CENELEC HD21.5, DEF STAN, DEF STAN 61-12 Part 6, VD0281-5, UL1581 VW-1, UL, TS 9760 HD 21.5.S3, RoHS, REACH, Mil Spec, ISO9001, IEC 60332-1-2, IEC60332-1, IEC 60228 Css 5, IEC 60227-5, HAR, H07V2-K
Maximum Operating Temperature:
150°C
Minimum Operating Temperature:
-50°C
