Avago ASMT-Bx20 Series LEDs
PCB Based Subminiature Lamps (PCB PolyLED)
The ASMT-Bx20 are environmentally friendly LEDs. These PolyLED lamps are un-tinted and non diffused and have a small, narrow footprint. They offer quality and high reliability. With a high brightness, the ASMT-Bx20 LEDs are ideal for backlighting, status indication and panel illumination applications.
Low power consumption
Non-diffused dome for high brightness
Operating temperature range of -40°C to +85°C
Package in 8mm tape on 7 inch diameter reels
Compatible with automated placement equipment
Compatible with infrared and vapor phase reflow soldering process.
The ASMT-Bx20 are environmentally friendly LEDs. These PolyLED lamps are un-tinted and non diffused and have a small, narrow footprint. They offer quality and high reliability. With a high brightness, the ASMT-Bx20 LEDs are ideal for backlighting, status indication and panel illumination applications.
Low power consumption
Non-diffused dome for high brightness
Operating temperature range of -40°C to +85°C
Package in 8mm tape on 7 inch diameter reels
Compatible with automated placement equipment
Compatible with infrared and vapor phase reflow soldering process.
2 V Red LED 3224 (1209) SMD, ASMT-BR20-AS000
Manufacturer:
BroadcomManufacturer Part No:
ASMT-BR20-AS000
Enrgtech Part No:
ET14000654
Warranty:
Manufacturer
£ 0.29
Checking for live stock
LED Colours:
Red
Package Type:
3224 (1209)
Mounting Type:
Surface Mount
Number of LEDs:
1
Forward Voltage:
2 V
Luminous Intensity:
650 mcd
Number of Pins:
2
Viewing Angle:
15 °
Lens Shape:
Dome
Dominant Wavelength:
626 nm
Lens Colour:
Clear
Dimensions:
3.2 x 2.4 x 2.4mm
