The Renesas RA4M1 group uses the high-performance Arm® Cortex®-M4F core and offers a Segment LCD Controller and a Capacitive Touch Sensing Unit input for intensive HMI designs. The RA4M1 is built on a highly efficient low power process and is supported by an open and flexible ecosystem concept—the Flexible Software Package (FSP), built on FreeRTOS—and is expandable to use other RTOSes and middleware. The RA4M1 is suitable for applications where a large amount of Capacitive Touch channels and a Segment LCD controller are required. 48MHz Arm® Cortex®-M4F
256kB Flash Memory and 32kB SRAM
8kB DataFlash to store data as in EEPROM
Scalable from 40pin to 100pin Packages
Segment LCD Controller
14-bit A/D Converter
Capacitive Touch Sensing Unit
USB2.0 Full Speed
CAN 2.0B
SCI (UART, Simple SPI, Simple I2C)
SPI/ I2C Multimaster Interface
Applications
HMI with Seg/Com LCD display
Security (Fire Detection, Burglar Detection, Panel Control)
Industry (Door Openers, Panel Control)
HVAC (Heating, Air Conditioning, Boiler Control)
Home Appliance
General Purpose
