HIP4020, Full-Bridge Driver with 500mA Power FETs, Intersil
Two Independent Controlled Complementary MOS Power Output Half-Bridge Drivers (Full-Bridge)
Split Voltage Power Supply Option for Output Drivers
Single Supply Range 2.5 V to 15 V
Low Standby Current
Split Voltage Power Supply Option for Output Drivers
Single Supply Range 2.5 V to 15 V
Low Standby Current
HIP4020IBZ, DC Motor Driver IC, 15 V 0.5A 20-Pin, SOIC W
Manufacturer:
Renesas Electronics
Manufacturer Part No:
HIP4020IBZ
Enrgtech Part No:
ET16787966
Warranty:
Manufacturer
£ 3.32
Checking for live stock
Motor Type:
DC
Output Configuration:
Full Bridge
Maximum IGBT Collector Current:
0.5A
Maximum Collector Emitter Voltage:
15 V
Mounting Type:
Surface Mount
Package Type:
SOIC W
Maximum Operating Supply Voltage:
15 V
Pin Count:
20
Minimum Operating Supply Voltage:
3 V
Minimum Operating Temperature:
-40 °C
Width:
7.6mm
Dimensions:
13 x 7.6 x 2.35mm
