35XPA Handheld Digital Multimeter, 2A ac Max, 2A dc Max, 600V ac Max - RS Calibrated

Multimeter Type:

Handheld

Display Type:

Digital

Model Number p:

35XPA

Calibrated:

RSCAL

Functions Measured:

AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature

Absolute Maximum DC Voltage Measurement:

600V dc

Absolute Maximum AC Current Measurement:

2A ac

Absolute Maximum Resistance Measurement:

40MΩ

Absolute Maximum DC Current Measurement:

2A dc

Absolute Maximum AC Voltage Measurement:

600V ac

Absolute Maximum Capacitance Measurement:

4mF

Absolute Maximum Temperature Measurement:

+1000°C

Maximum Frequency:

500Hz

AC Current Measurement Resolution:

0.1µA ac

DC Current Measurement Resolution:

0.1µA dc

AC Voltage Measurement Resolution:

100µV ac

DC Voltage Measurement Resolution:

100µV dc

Resistance Measurement Resolution:

100mΩ

Temperature Measurement Resolution:

0.1°C

Safety Category Level:

CAT I, CAT II, CAT III

Capacitance Measurement Resolution:

1pF

Best Temperature Measurement Accuracy:

±3% + 2 °C

Safety Category Voltage:

600V

Battery Type:

9V

Height:

155mm

Best AC Current Accuracy:

±2.5% + 5 Digits

Width:

72mm

Length:

32mm

Best DC Current Accuracy:

±2% + 3 Digits

Weight:

400g

Dimensions:

32 x 72 x 155mm

Best DC Voltage Accuracy:

±0.5% + 1 Digit

Minimum Operating Temperature:

0°C

Maximum Operating Temperature:

+50°C

Best AC Voltage Accuracy:

±1.5% + 5 Digits

Best Resistance Measurement Accuracy:

±2% + 5 Digits

Best Capacitance Measurement Accuracy:

±5% + 15 Digits
