Series:
SEFRAM7212
Weight:
268g
True RMS:
Yes
Battery Type:
AAA
Display Type:
LCD
Model Number:
SEFRAM7212
Power Source:
Battery
Product Type:
Multimeter
Multimeter Type:
Digital
Maximum Frequency:
10MHz
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Resistance
AC Current Accuracy:
±1 % rdg + 5 Digits
AC Voltage Accuracy:
±0.8 % rdg + 3 Digits
DC Current Accuracy:
±0.8 % rdg + 3 Digits
DC Voltage Accuracy:
±0.5 % rdg + 3 Digits
Standards/Approvals:
EN: 610101, EN: 6101002033, EN: 61326, EN: 6101002032
AC Current Resolution:
10mA ac
AC Voltage Resolution:
100mV ac
DC Current Resolution:
10mA dc
DC Voltage Resolution:
10 μV dc to 100 mV dc
Safety Category Level:
CAT III
Safety Category Voltage:
600V ac
Maximum Operating Temperature:
40°C
Minimum Operating Temperature:
0°C
Maximum AC Current Measurement:
10A ac
Maximum AC Voltage Measurement:
600V ac
Maximum DC Current Measurement:
10A dc
Maximum DC Voltage Measurement:
600V dc
Maximum Resistance Measurement:
60mΩ
Resistance Measurement Accuracy:
±1.2 % rdg + 5 Digits
