Multimeter Type:
Handheld
Model Number p:
MX 1
Display Type:
Analogue
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum Resistance Measurement:
20kΩ
Absolute Maximum AC Current Measurement:
10A ac
True RMS:
No
Maximum Frequency:
1000Hz
Capacitance Measurement Resolution:
0828072
Safety Category Level:
CAT III
Safety Category:
CAT III 600V
Width:
98mm
Length:
40mm
Safety Category Voltage:
600V
Battery Type:
AA
Best Resistance Measurement Accuracy:
±10 %
Maximum Operating Temperature:
+50°C
Height:
150mm
Weight:
420g
Best DC Current Accuracy:
±2 %
Dimensions:
40 x 98 x 150mm
Best DC Voltage Accuracy:
±2 %
Best AC Voltage Accuracy:
±2.5 %
Minimum Operating Temperature:
-10°C
Best AC Current Accuracy:
±2.5 %
