Width:
252.8mm
Height:
107mm
Length:
305mm
Series:
2110
Weight:
2.23kg
True RMS:
Yes
Display Type:
Digital
Model Number:
2110-100
Power Source:
100/120/220/240 V
Product Type:
Multimeter
Multimeter Type:
Bench
Maximum Frequency:
15MHz
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Temperature
AC Current Accuracy:
0.30 + 0.06 % of reading + % of range
AC Voltage Accuracy:
±0.12 % rdg + 0.05 % range
DC Current Accuracy:
±0.05 % rdg + 0.02 % range
DC Voltage Accuracy:
±0.012 % rdg + 0.004 % range
Standards/Approvals:
IEC 8012, European Union EMC and Low Voltage, MILT28800E1, CAN/CSAC22.2 No. 231, FCC Part 15 Class B, IEC348, UL1244, VDE 0871B, CISPR22 (EN55022)
AC Voltage Resolution:
10mV ac
DC Current Resolution:
0.1μA ac
DC Voltage Resolution:
1 V dc
Resistance Resolution:
100mΩ
Safety Category Level:
CAT I, CAT II
Other Measurement Range:
Temperature: -250 to 1800°C
Safety Category Voltage:
1000V dc
Other Measurement Accuracy:
Frequency: ±0.1 % of reading
Maximum Operating Temperature:
40°C
Minimum Operating Temperature:
0°C
Maximum AC Current Measurement:
10A ac
Maximum AC Voltage Measurement:
750V ac
Maximum DC Current Measurement:
10A dc
Maximum DC Voltage Measurement:
1kV dc
Maximum Resistance Measurement:
1GΩ
Resistance Measurement Accuracy:
0.02 % rdg + 0.002 % range
