Coil Voltage:
12V dc
Contact Configuration:
SPDT
Mounting Type:
Surface Mount
Switching Current:
4A
Number of Poles:
1
Latching:
No
Series:
IM
Terminal Type:
Surface Mount
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
220V dc
Length:
10mm
Coil Resistance:
1029Ω
Coil Power:
140mW
Minimum Operating Temperature:
-40°C
Height:
5.7mm
Maximum Operating Temperature:
+85°C
Life:
100000000 (Mechanical) operations, 2500000 (Electrical) operations
Standards Met:
UL 508 File No. E 111441
Isolation Coil To Contact:
1.8kVrms
Contact Material:
Palladium-Ruthenium
Depth:
6mm
Maximum Switching Power AC:
62.5VA
Maximum Switching Power DC:
60 W
Application:
Access & Transmission Equipment, Consumer Electronics, Industrial Controls, Measurement & Test Equipment, Medical Equipment, Modems, Office & Business Equipment, Optical Network Terminals, Telecommunication
