Legend:
Blank
Length:
35.5mm
Series:
82
IP Rating:
IP65, IP67
LED Colour:
White
Mount Type:
Panel
Illuminated:
Yes
Product Type:
Push Button Switch
Actuator Style:
Flat
Switch Operation:
Momentary
Panel Cutout Size:
19 mm
Contact AC Voltage:
240V ac
Contact DC Voltage:
240V dc
Standards/Approvals:
CB, cUL, CCC, UL
Contact Configuration:
SPDT
Switch Contact Current:
3A
Maximum Operating Temperature:
70°C
Minimum Operating Temperature:
-30°C
ECCN:
EAR99
Type:
Standard, Illuminated
HTSUS:
8536.50.9031
Legend:
Blank
Series:
82
Circuit:
SPDT
Features:
Stainless Steel
IP Rating:
IP65, IP67
Packaging:
Bulk
LED Colour:
White
Case Colour:
Silver
Illuminated:
Yes
RoHS Status:
ROHS3 Compliant
REACH Status:
REACH Affected
Actuator Type:
Round, Button, Flush
Mounting Type:
Panel Mount, Front
Terminal Type:
Plug In, Solder
Voltage Rating:
240V
Electrical Life:
50,000 Cycles
Mechanical Life:
1,000,000 Cycles
Switch Function:
On-Mom
Actuator Marking:
No Marking
Contact Material:
Silver Alloy
Switch Operation:
Momentary
standardLeadTime:
14 Weeks
Termination Style:
Solder, Quick Connect - 0.110" (2.8mm)
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
Base Product Number:
82-5151
Voltage Rating - AC:
240 V
Voltage Rating - DC:
240 V
Color - Actuator/Cap:
Silver
Contact Configuration:
SPDT
Current Rating (Amps):
3A (AC/DC)
Manufacturer Part No.:
82-5151.1154
Operating Temperature:
-30°C ~ 70°C
Contact Current Rating:
3A
Panel Cut Out Diameter:
19mm
Panel Cutout Dimensions:
Circular - 19.00mm Dia
Illumination Type, Color:
LED, White
Contact AC Voltage Rating:
240V
Contact DC Voltage Rating:
240V
Operating Temperature Range:
-30°C to +70°C
Maximum Operating Temperature:
+70°C
Minimum Operating Temperature:
-30°C
Illumination Voltage (Nominal):
24 VAC/DC
Moisture Sensitivity Level (MSL):
Not Applicable
