v23100v4012a000 TE Connectivity PCB Mount Reed Relay, 12V dc Coil, SPST, 200V dc Max, 1 A Max, 1000Ω
v23100v4012a000 TE Connectivity PCB Mount Reed Relay, 12V dc Coil, SPST, 200V dc Max, 1 A Max, 1000Ω
v23100v4012a000 TE Connectivity PCB Mount Reed Relay, 12V dc Coil, SPST, 200V dc Max, 1 A Max, 1000Ω

TE Connectivity PCB Mount Reed Relay, 12V dc Coil, SPST, 200V dc Max, 1 A Max, 1000Ω

TE Connectivity PCB Mount Reed Relay, 12V dc Coil, SPST, 200V dc Max, 1 A Max, 1000Ω

Manufacturer:
TE Connectivity
Manufacturer Part No:
V23100V4012A000
Enrgtech Part No:
ET100374119
Warranty:
Manufacturer
£ 9.86 £ 9.86
Checking for live stock
Contact Configuration:
SPST
Coil Voltage:
12V dc
Mounting Type:
PCB Mount
Maximum Switching Current AC:
1 A
Maximum Switching Current DC:
1 A
Maximum Switching Voltage AC:
200V ac
Maximum Switching Voltage DC:
200V dc
Coil Power:
144mW
Coil Resistance:
1000Ω
Length:
19.3mm
Height:
5.7mm
Depth:
6.4mm
Dimensions:
19.3 x 6.4 x 5.7mm
Isolation Coil To Contact:
1.5kV rms
Minimum Operating Temperature:
-40°C
Maximum Operating Temperature:
+85°C
Life:
50000000 (Electrical) cycles
Maximum Switching Power AC:
10VA
Operating Temperature Range:
-40 → +85°C
Terminal Type:
Through Hole
Contact Material:
Ruthenium
Contact Resistance:
150 mΩ
Maximum Switching Power DC:
10 W
Operating Time Including Bounce:
0.75ms
pdf icon
0900766b813980cb.pdf(datasheets)
