4-1393763-0 TE Connectivity PCB Mount Reed Relay, 24V dc Coil, SPDT, 175V dc Max, 2000Ω
4-1393763-0 TE Connectivity PCB Mount Reed Relay, 24V dc Coil, SPDT, 175V dc Max, 2000Ω
4-1393763-0 TE Connectivity PCB Mount Reed Relay, 24V dc Coil, SPDT, 175V dc Max, 2000Ω

TE Connectivity PCB Mount Reed Relay, 24V dc Coil, SPDT, 175V dc Max, 2000Ω

TE Connectivity PCB Mount Reed Relay, 24V dc Coil, SPDT, 175V dc Max, 2000Ω

Manufacturer:
TE Connectivity
Manufacturer Part No:
4-1393763-0
Enrgtech Part No:
ET13917150
Warranty:
Manufacturer
£ 18.14 £ 18.14
Checking for live stock
Contact Configuration:
SPDT
Coil Voltage:
24V dc
Mounting Type:
PCB Mount
Maximum Switching Voltage AC:
175V ac
Maximum Switching Voltage DC:
175V dc
Coil Power:
288mW
Coil Resistance:
2000Ω
Length:
19.3mm
Height:
7.5mm
Depth:
7mm
Dimensions:
19.3 x 7 x 7.5mm
Isolation Coil To Contact:
1.5kV rms
Maximum Switching Power AC:
3VA
Life:
5000000 (Electrical) cycles
Minimum Operating Temperature:
-40°C
Maximum Operating Temperature:
+85°C
Operating Temperature Range:
-40 → +85°C
Operating Time Including Bounce:
1.1ms
Terminal Type:
Through Hole
Special Features:
High Vibration and Shock Resistance, Highly Reliable Switching
Contact Resistance:
150 mΩ
Contact Material:
Ruthenium
Maximum Switching Power DC:
3 W
Number of Poles:
1
pdf icon
A700000006791916.pdf(datasheets)
