Small footprint: 2 x 2 x 0.9 mm LGA 12-pin package (pin-to-pin compatible with KXTJ2)
Low current consumption: 0.9 μA in standby, 10 μA in Low Power, and 155 μA in High Resolution modes
Extended user-configurable g-ranges: ±2g, ±4g, ±8g, ±16g
8-bit, 12-bit, and 14-bit resolution modes
Wide supply voltage range: 1.71V – 3.6V with internal voltage regulator
High resolution Wake-Up function with threshold configurable down to 3.9 mg
User-configurable Output Data Rates from 0.781Hz to 1600Hz
I2C digital communication interface up to 3.4MHz
Highly configurable interrupt control
Embedded Low Pass filter
Improved design to virtually eliminate post reflow offset and sensitivity shifts
Improved noise performance
Stable performance over temperature
High shock survivability
Self-test function
